Model

CMT-F1212

CMT-F1225

CMT-F1830

CMT-G2515

CMT-G3020

CMT-4020



Structure

F-Flying arm

F- Flying arm

F- Flying arm

G-Gantry

G-Gantry

G-Gantry

Journey

X

1250mm (48″)

1250mm (48″)

1850mm (72″)

2500mm (96″)

3050mm (120″)

4000mm (156″)

Y

1250mm (48″)

2500mm (96″)

3050mm (120″)

1525mm (60″)

2000mm (78″)

2000mm (78″)

Z

155mm  (6″)

155mm  (6″)

155mm  (6″)

200mm (8″)

200mm (8″)

200mm (8″)

CNC

Windows XP. Japan servo motors, G-code running and PC based Windows XP

 Accuracy

Control

±0.01mm

Repeatability

±0.05mm

Cutting

±0.1mm

Idle running speed

0~6m/min

0~8m/min

0~8m/min

0~10m/min

0~15m/min

0~15m/min

High pressure pump

KMT Jetline 50HP (37kw).55k psi,3 shifts

Power supply

380V/50Hz/3ph or as request, 50KVA

Different table size, high pressure pump and CNC can be customized according to the application and budget of the customers.

Other features such as dual cutting heads, drilling or tapping cutting head, submerged cutting, skip&float for uneven plate cutting and so on are available upon request
